Wheel Loader
This product has been online for: 5 years, 3 months and 6 days
Operating weight
11.640 kg
Bucket capacity
1,9 m³
Engine type
4 cylinders – EU Stage IV compliant
Max. engine performance (SAE J1995 gross)
142 hp (106 kW) at 2.200 RPM
Max. torque
560 Nm at 1.400 rpm
Static tipping load (straight / at full turn)
9.635 kg / 8.510 kg
Height at bucket pivot point (Standard lift / High lift)
3.730 mm / 4.200 mm
Breakout force
100 kN
Standard tyres
20.5 R25
Wheelbase
2.900 mm
Turning radius (tyre side / bucket edge)
5.245 mm / 5.795 mm
Overall length
7.135 mm
Overall height
3.280 mm
