E 110 B CAT

Engine
Make
2236
Model
3114
Gross Power
79.1 hp
59 kw
Displacement
268.5 cu in
4.4 L
Operational
Operating Weight
25573.6 lb
11600 kg
Fuel Capacity
66 gal
250 L
Hydrauilc System Fluid Capacity
42.3 gal
160 L
Hydraulic System Relief Valve Pressure
4270 psi
29440.6 kPa
Hydraulic Pump Flow Capacity
56.5 gal/min
214 L/min
Undercarriage
Shoe Size
19.7 in
500 mm
Ground Pressure
5.7 psi
39.2 kPa
Max Travel Speed
3.1 mph
5 km/h
Drawbar Pull
19333.6 lb
86 kN
Track Gauge
6.5 ft in
1990 mm
Boom/Stick Option (HEX) 1
Boom/Stick Option (HEX) 1
Stick 6’5″ (1950mm)
Max Digging Depth
15.6 ft in
4750 mm
Max Reach Along Ground
23.9 ft in
7295 mm
Max Cutting Height
25.1 ft in
7655 mm
Max Loading Height
17.4 ft in
5290 mm
Max Vertical Wall Digging Depth
13.9 ft in
4225 mm
Boom/Stick Option (HEX) 2
Boom/Stick Option (HEX) 2
Stick 7’5″ (2250mm)
Max Digging Depth
16.6 ft in
5050 mm
Max Reach Along Ground
24.8 ft in
7570 mm
Max Cutting Height
25.6 ft in
7795 mm
Max Loading Height
17.8 ft in
5440 mm
Max Vertical Wall Digging Depth
14.6 ft in
4450 mm
Boom/Stick Option (HEX) 3
Boom/Stick Option (HEX) 3
Stick 9’2″ (2800mm)
Max Digging Depth
18.4 ft in
5600 mm
Max Reach Along Ground
26.6 ft in
8100 mm
Max Cutting Height
26.6 ft in
8120 mm
Max Loading Height
18.9 ft in
5765 mm
Max Vertical Wall Digging Depth
16.3 ft in
4965 mm
Dimensions
Width to Outside of Tracks
8.2 ft in
2490 mm
Height to Top of Cab
8.9 ft in
2700 mm
Ground Clearance
1.5 ft in
460 mm
Removal Counterweight Clearance
3 ft in
920 mm
Tail Swing Radius
6.9 ft in
2090 mm
Length of Track on Ground
8.6 ft in
2610 mm
