Dahua 2MP Super Starlight HD Network Water – proof Dome Camera-TD-9524S1H（D/PE/AR1)

Widely used in large-scale high-definition quality monitoring of the places, such as: forests, highways, railways, airports, ports, sentries, squares, parks, scenic spots, streets, stations, large venues, residential and other places.”

Features
2MP ( 1920 x 1080 ) full real *time coding
Max resolution: 1920 x 1080
ICR auto .switch, true day / night
10 ~ 20 m IR night view distance
3D DNR, digital WDR
ROI coding
PoE power supply optional
Support smart phone, iPad, remote monitoring
Support P2P
IP66 ingress protection
Support three streams
Model Specification TD-9524S1H（D/AR1) TD-9524S1H（D/PE/AR1)
Camera
Image Sensor 1 / 2.8 “CMOS
Image Size 1920 x 1080
Electronic Shutter 1 / 25s~ 1 /100000 s
Iris Type Fixed Iris
Min. Illumination Color : 0.002 lux @F1.2,AGC ON; B/W : 0.0002 lux @F1.2, AGC ON
Lens 2.8 mm @ F1.6, horizontal field of view : 107° 3.6 mm @ F1.6, horizontal field of view : 85.8° 6 mm @ F1.6, horizontal field of view : 52.6°
Lens Mount M12
Day & Night ICR
Wide Dynamic Range Digital WDR
Digital NR 3D DNR
Angle Adjustment Any angle
Video Compression H.264 / MJPEG
H.264 Compression Standard Baseline Profile / Main Profile / High Profile
Resolution 1080P ( 1920 x 1080 ), 720P ( 1280 x 720 ), D1, CIF, 480 x 240
Main Stream 60Hz: 1080P(1 ~30fps)/720P(1 ~30fps) 50Hz: 1080P(1 ~25fps)/720P(1 ~25fps)
Bit Rate 128Kbps~6Mbps
Bit Rate Type VBR/CBR
Quality Five levels under VBR; Freely adjustable under CBR
Image Settings ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic, Sharpen, NR,etc. adjustable through client software or web browser
ROI Each ROI to be configured separately
Interfaces
Network RJ45
Functions
Remote Monitoring IE browsing,CMS remote control
Online Connection Support simultaneous monitoring for up to 3 users ; Support multi-stream real time transmission
Network Protocol TCP/IP, UDP, DHCP, NTP, RTSP, DDNS, SMTP,FTP
Interface Protocol ONVIF
Storage Network remote storage
Smart Alarm Motion alarm
PoE Not Support IEEE802.3 af
IR Distance 10 ~ 20 m
Ingress Protection IP66
Others
Power Supply DC12V DC12V/PoE
Power Consumption < 3W
IR Consumption ON < 5W
Operating Environment -20°C ~ 50°C,10% ~ 90% relative humidity
Dimensions ( mm ) 087 x 108
Weight ( net ) 401g
