2.5MP Sony Bullet Camera

1x 4CH 1080N AHD DVR

4x 2.5MP Sony IR Bullet Camera 3.6mm

1X 1 500GB HDD

8X BNC Connectors

4X DC Power jacks

100 Meters 3C2V 75 Ohm Video cable

12V-5Amp 4ch power splitor

12V- 2A power adapter

1x USB mouse

SPECIAL DISCOUNT FOR DEALERS
Model
AVR1104SH4205N
Package
DVR
1x4CH 1080N/960N/720P/960H HD-DVR AVR-1104N
Camera
4xIR Waterproof Bullet 1080P True Color Cameras SH4205N/IR2
HDD
500GB Hard Disk Drive
Video Cable
100 Meters 3C2V 75 Ohm Copper cable
BNC Connectors
8 BNC

Mouse
1xUSB 2.0 Mouse
Power Adaptor
12V-5Amp 1x4CH Cental Power Adaptor Cable
Adaptor
12V-2A Power Adaptor (US, EU, UK, AU Plug is Optional)
Weight
6KGS/SET
AHD DVR System
Input
4 channel, BNC
HDAHD
4CH 1080P/960P/ 720P HDAHD Camera
Analog
NTSC/PAL
IP
Support 4ch 720P IP Camera
Audio Input
4 channel, RCA
Interface
1 HDMI, 1 VGA, CVBS(BNC Output)
Resolution
1920×1080, 1280×1024, 1280×720, 1024×768
Display Split
1/4
Privacy Masking
4 rectangular zones (each camera)
Video/Audio Compression
H.264/ADPCM
Main Stream
1080N/960P/ 720P/960H/D1(1~25/30fps)
Bit Rate
80~4096Kb/s
Record Mode
Manual, Schedule(Regular(Continuous), MD), Stop
Sync Playback
1/4
Search Mode
Time/Date, MD & Exact search (accurate to second)
Playback Functions
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode
USB Device/Internal SATA burner/Network
Ethernet
RJ-45 port (10/100M)
Network Functions
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P
Max. User Access
128 users
Smart Phone
iPhone, iPad, Android, Windows Phone
Internal HDD
1 SATA port, up to 4TB
USB Interface
2 ports(2 Rear), USB2.0
Camera
Image Sensor
1/2.8 2.0 MegaPixel SONY Sensor
Effective Pixels
1960(H)× 1080(V)
Electronic Shutter
1/50s~1/100,000s
Video Frame Rate
25fps@ 1080P
Synchronization
Internal
Min. Illumination
0.01Lux@F1.2(AGC ON), 0Lux IR on
OSD
Optional
Video Output
1-channel BNC HDAHD high definition video output
Max. IR LEDs Length
60M, Smart IR
Infrared LED
4 Big Array IR LED
Day/Night
Auto(ICR) / Color / B/W
Noise Reduction
2D
Focal Length
3.6 mm fixed lens
Angle of View
H: 82º(99º/51.4º)
Mount Type
M12
Power Supply
DC12V±20%
Power Consumption
